SV-5505-W Waters Barndominium House Plan

$849.99 USD
$849.99 USD
Sale Sold out
Add To Wishlist
1 10

Floor Plan

DETAILS

HEATED SQ FT

First Floor:

1,500 SF

Second Floor:

1,108 SF

Total Heated Sq Ft:

2,608 SF

UNHEATED SQ FT

Total Unheated Area:

Porch 1,408 SF, Deck 400 SF = TOTAL 1,808 SF

Carport:

None

Bedrooms:

4

Full Baths:

3

Floors:

2

Garage Size:

None

Width:

66'

Depth:

38'

Height:

24'-8 1/2"

Foundation:

Concrete Slab

Main Roof Pitch:

4:12

Exterior Framing:

Metal Shell

CEILING HEIGHTS

First Floor:

9'

SV-5505-W Waters Barndominium House Plan



About this barndominium house plan:

  • 2,608 Heated Sq Ft
  • 4 bedrooms
  • 3 bathrooms
  • Open Concept
  • Two Story
  • J&J Bathroom
  • Mudroom/Laundry
  • Rear porch
  • Rear Deck
  • Wraparound porch



  • A versatile two-level layout offering 2,608 square feet of conditioned space.
  • Four bedrooms are distributed across two floors—balancing privacy and accessibility, with a Jack & Jill bath connecting two secondary rooms.
  • A practical entry zone streamlines household tasks and keeps the main living areas clean and organized.
  • Dual outdoor zones at the back of the home offer shaded lounging and open-air entertaining—perfect for morning coffee or sunset gatherings.
  • A full-perimeter porch adds architectural charm and breezy transitions—enhancing curb appeal and outdoor living from every angle.



What's included in SV-5505-W:

Cover Page
First Floor Plan
Second Floor Plan
Roof Plan
Elevations
First Floor Electrical Plan
Second Floor Electrical Plan
First Floor Plumbing Plan
Second Floor Plumbing Plan
First Floor HVAC Plan
Second Floor HVAC Plan
Roof Framing Plan
Foundation Plan
Foundation Detail
Interior Bearing Footing
C-Typical Column Detail
Wall Section



For more barndominium floor plans, check out our complete collection of 4-bedroom barndominium floor plans.



Need to make changes? Submit a modification request using the button that says Modify This Plan. We will get you a free price quote within 72 hours.

What's Typically Included

THE SPECIFC DETAILS OF WHAT'S INCLUDED ON THESE PLANS IS CONTAINED IN THE PRODUCT DESCRIPTION. PLEASE SCROLL UP AND YOU WILL FIND IT UNDER "WHAT'S INCLUDED"

Our house plan sets typically have the following details:

4 Elevations – Front, Back, Both Sides

Detailed Floor Plan Drawing

Electrical Plans with placements for HVAC

Plumbing Plans with Placements

Flooring Plan

Roof Plan

Foundation Plan

For more information on what's included and examples of what your plans will look like, go here -> https://barndominiumplans.com/pages/whats-included

Please Note: We work with many different draftspeople who work in many different ways.  It should be noted that their plans may contain different details. THE SPECIFC DETAILS OF WHAT'S INCLUDED ON THESE PLANS IS CONTAINED IN THE PRODUCT DESCRIPTION. PLEASE SCROLL UP AND YOU WILL FIND IT UNDER "WHAT'S INCLUDED"

What's Not Included

The following items are NOT included:

Architectural or Engineering Stamp. Our plans are engineering-ready! Can take them to a local engineer in your state.

Site Plan - We can provide this if needed for $300 additional.

Materials List - handled locally when required

Energy calculations - handled locally when required

Snow load calculations - handled locally when required

Delivery

This plan is available as a digital product or printed + shipped.

If you select digital, the plan will be delivered to you via email as a PDF file, no matter what time it is.

If you select printed + shipped, your order will ship in 24x36 format within 1 business day of your order.

We ship from the midwest in order to serve the entire country within 3-5 business days!

Return policy

All barndominium house plan purchases are FINAL. There are no exchanges or refunds due to the digital nature of the product. Please make sure that the plan you have selected is going to fit your needs.
